Control function
The conguration of this option should be done through the master controller
Conguration → Space cooling →Cycle 1
Mark Description Default Value Range Steps Units
Cycle 1_ Status Status Enabled Disabled /Enabled - -
Conguration → Space cooling → Cycle 2
Mark Description Default Value Range Steps Units
Cycle 2_ Status Status Disabled Disabled /Enabled - -
10.2.3.1
Set target outlet water temperature
Each of the 2 Water Cycles will have an independent target outlet water temperature. And Target outlet water temperature
is combination of Water Cycle set-point and compensation of Water ECO o󰀨set / Room thermostat.
(1) Cooling Water Cycle set-point can be dene as follows:
Ttwo_c1 _water_c_p as Water Cycle 1.
Ttwo_c2 _water_c_p as Water Cycle 2.
There are 2 ways to set Water Cycle set-point as follows:
● Fixed, refer to 1.2.3.1.1 (1)
● OTC point, refer to 1.2.3.1.1 (2)
(2) Cooling Compensation of Water ECO o󰀨set dened as following, refer to 1.2.3.1.2
c1_wate_c_Ecoofs as Water Cycle 1.
c2_wate_c_Ecoofs as Water Cycle 2.
NOTE: Compensation of Water ECO oset is valid when the function is active.
(3) Cooling Compensation of Room thermostat dened as following, refer to 1.2.3.1.3
Compenc_c1 as Water Cycle 1.
Compenc_c2 as Water Cycle 2.
NOTE: Compensation of Room thermostat is valid when the function is active.
(4) Cooling Target outlet water temperature dened as
Ttwo_Cycle 1_c as Water Cycle 1.
Ttwo_Cycle 2_c as Water Cycle 2.
Cooling Target outlet water temperature is combination of Water Cycle set-point and compensation of Water ECO o󰀨set
and Room thermostat.
Ttwo_Cycle 1_c= Ttwo_c1 _water_c_p - Compenc_c1 + c1_wate_c_Ecoofs
Ttwo_Cycle 2_c= Ttwo_c2 _water_c_p - Compenc_c2 + c2_wate_c_Ecoofs
NOTE: Compenh_c1 and Compenh_c2 is forced as 0 when water Calculation Regulation Mode set as [ Fix ].
(5) Cooling Target outlet water temperature is regulated as following scope
c1_wate_c_min ≤ Ttwo_Cycle 1_c ≤ c1_wate_c_max
c2_wate_c_min ≤ Ttwo_Cycle 1_c ≤ c2_wate_c_max
The conguration of this option should be done through the master controller
Conguration → Space cooling→Cycle 1→ Working range
Mark Description Default Value Range Steps Units
c1_wate_c_max Max. Water Supply Temp 22 19~22 1 °C
c1_wate_c_min Min. water Supply Temp 12 5~18 1 °C
Conguration → Space cooling→Cycle 2→ Working range
Mark Description Default Value Range Steps Units
c2_wate_c_max Max. Water Supply Temp 22 19~22 1 °C
c2_wate_c_min Min. water Supply Temp 12 5~18 1 °C
NOTE
：
1. It is the installer’s responsibility to make sure no unwanted situation occurs (for example: water temperature setting too
low into Refreshing oor installation).
2. In case of Radiator and Refreshing oor installation, Radiators valve should be closed and disabled by user and the
system only works for refreshing oor.
