232
Control function
10.2.3.1.1 Water temperature set-point
Water Cycle set-point can be set as follows:
The conguration of this option should be done through the master controller
Conguration → Space cooling→Cycle 1
Mark Description Default Value Range Steps Units
Cycle 1 Water Regulation Mode
Fixed
OTC point
Fixed - -
Conguration → Space cooling→Cycle 2
Mark Description Default Value Range Steps Units
Cycle 2 Water Regulation Mode
Fixed
OTC point
Fixed - -
(1) Fixed
Setting outlet water temperature is a xed temperature set by the user on master controller . Refer to master controller
manual.
The conguration of this option should be done through the master controller
.
Main Interface → Space cooling→Cycle 1
Mark Description Default Value Range Steps Units
Ttwo_c1 _water_c_p Cycle 1 water temperature set-point 12
c1_wate_c_min~
c1_wate_c_max
1 °C
Main Interface → Space cooling→Cycle 2
Mark Description Default Value Range Steps Units
Ttwo_c2 _water_c_p Cycle 2 water temperature set-point 12
c2_wate_c_min~
c2_wate_c_max
1 °C
(2) OTC point
The weather-dependent set-point denes the parameters for weather-dependent operation of the unit. When
weather-dependent operation is active the water temperature is determined automatically depending on the outdoor
temperature: higher outdoor temperatures will result in colder water and vice versa.
OTC Points system will use average outdoor ambient temperature in order to get the water temperature set-point. Water
set-point will be determined using the following rule.
①
Water temperature set point of Water Cycle 1: Ttwo_c1 _water_c_p as following
Outdoor ambient
temperature(°C)
Tac1h
Tac1l
Tsc1l
Tsc1h
The conguration of this option should be done through the master controller
