Control function
10.10 Input /Output /Auxiliary sensors
NOTE:
1. After changing the input settings, output settings and auxiliary sensor settings on the master controller, it needs to be
powered o and on again to take eect.
10.10.1 Input
The unit o󰀨ers 11 optional input ports that can be congured as di󰀨erent function.
The conguration of this option should be done through the master controller.
Conguration →I/O →Inputs
Mark Description Default Value Range
Terminals
ON board
Terminals
ON PCB1
Specication
ON board
i1 Input 1
08
(Demand ON/OFF1)
00~17
(except 07, 12)
I1, L1
on TB3
PCN4-1
Closed/Open
220-240V ~
50/60Hz
i2 Input 2
13
(Cycle 1 and 2 ECO
mode)
00~17
(except 07, 12)
I2, +12V
on TB4
CN2-1 Closed/Open 12V DC
i3 Input 3
00
(No Function)
00~17
(except 07, 12)
I3, L3
on TB3
PCN10-3
Closed/Open 220-240V ~
50/60Hz
i4 Input 4
04
(Solar in)
00~17
(except 07, 12)
I4, L3
on TB3
PCN10-1
Closed/Open 220-240V ~
50/60Hz
i5 Input 5
02
(Smart Act.)
00~17
(except 07, 12)
I5, +12V
on TB4
CN2-3 Closed/Open 12V DC
i6 Input 6
06
(DHW boost)
00~17
(except 07, 12)
I6, L3
on TB3
PCN10-5
Closed/Open 220-240V ~
50/60Hz
i7 Input 7
07
(Power meter 1)
00~17
I7, COM
on TB4
JL-1 Closed/Open 12V DC
i8 Input 8
12
(Power meter2)
00~17
I8, COM
on TB4
JL-2 Closed/Open 12V DC
i9 Input 9
09
(Demand ON/OFF2)
00~17
(except 07, 12)
I9, +12V
on TB4
CN11-3 Closed/Open 12V DC
i10 Input 10
00
(No Function)
00~17
(except 07, 12)
I10, +12V
on TB4
CN11-4 Closed/Open 12V DC
i11 Input 11
00
(No Function)
00~17
(except 07, 12)
I11, +12V
on TB4
CN11-4
Closed/Open
12V DC
Optional function can be congured.
Input
codes
Mark Description
00 No Function -
02
Smart Act./ SG
Ready Input 1
This function must be used to stop or limit the heat pump and Auxiliary electric heater when restricted by
Electric company. It allows an external Smart switch device to switch o󰀨 or reduce consumption of the
heat pump and Auxiliary electric heater during time of peak electricity demand.
In case of using Smart Grid application, this input is used as a digital input 1 and allows four
di󰀨erent operating modes.
03
Swimming pool
Demand ON/OFF
Optional input signal can be congured as function of “”Swimming pool Demand ON/OFF”” to operate
SWP. Switch ON/OFF of SWP can also be controlled by master controller.
Closed: Start SWP operation (Switch ON and Demand ON)
Open: Stop SWP operation (Switch OFF and Demand OFF)
04 Solar in
In case of combining Unit with solar panels, this input is used as a feedback for solar station ready
operation.
Closed: Solar in ON to trigger solar pump operation ON
Open: Solar in OFF to trigger solar pump operation OFF
05
Forced Heating/
Cooling
Heating/cooling can be changed by an input of an external contact signal. Heating/cooling can also be
changed over by master controller.
Closed: Heating mode
Open: Cooling mode
06 DHW Boost
With this function enabled, it is possible to request a heating up of the DHW when user requires an
instantaneous delivery of DHW. Triggering input signal can also Switch ON
DHW.
07 Power meter 1
Input used as kW/h pulse count for Energy data recording, used to count energy data or the total energy
data.
08 Demand ON/OFF 1
Optional input signal can be congured as function of “Demand ON/OFF 1” or “Demand ON/OFF 2” and
selected as room thermostat.
