Control function
10.10.2 Output
The unit o󰀨ers 15 optional output ports that can be congured as di󰀨erent function.
The conguration of this option should be done through the master controller.
Conguration →I/O →Outputs
Mark Descripti on Default Value Range Terminals ON board
Terminal
s ON PCB1
Specication ON board
o1 Output 1
01
（
3WV SWP
）
0~29
(except
17,02,21,08)
Power
supply
L2, N6 on
TB3
PCN9-3
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
Signal line O1 on TB3
o2 Output 2 02 (WP3)
0~30
(except 17)
O2, N2
on TB2
CN8-2
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o3 Output 3
03
(Boiler combination)
0~29
(except
17,02,21,08)
O3
on TB2
PCN14- 1 Free voltage
o4 Output 4
04
(Solar out)
0~29
(except
17,02,21,08)
O4
on TB3
PCN16- 1 Free voltage
o5 Output 5
17
(DHW Electric Heater)
0~30
HL, HN
on TB1
PCN15- 1
ON/OFF
220-240V ~ 50/60Hz Max. 13A
o6 Output 6
18
(3WV DHW)
0~29
(except
17,02,21,08)
Power
supply
L2, N6 on
TB3
PCN2-1
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
Signal line O6 on TB3
o7 Output 7
19
(Mixing valve Close)
0~29
(except
17,02,21,08)
O7, N4
on TB2
PCN12- 1
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o8 Output 8
20
(Mixing valve Open)
0~29
(except
17,02,21,08)
O8, N4
on TB2
PCN12- 3
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o9 Output 9 21 (WP2) 0~30(except 17)
O9, N1
on TB2
CN20-3
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o10 Output 10
22
(3WV Cooling)
0~29
(except
17,02,21,08)
Power
supply
Signal line
L1, N5 on
TB3
O10 on TB3
PCN8-1
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o11 Output 11
08
(WP1)
0~30
(except 17)
O11, N1
on TB2
CN20-2
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o12 Output 12
23
(Act1)
0~29
(except
17,02,21,08)
O12, N2
on TB2
CN8-3
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o13 Output 13
24
(Act2)
0~29
(except
17,02,21,08)
O13, N3
on TB2
PCN13-5
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o14 Output 14
25
(Act3)
0~29
(except
17,02,21,08)
O14, N3
on TB2
PCN13-3
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
o15 Output 15
26
(Act4)
0~29
(except
17,02,21,08)
O15, N4
on TB2
PCN13-1
ON/OFF
220-240V ~ 50/60Hz Max.
1.0A
