287
Control function
(7) DHW Boost
An input of an external contact signal of DHW Boost can be used to Switch ON of DHW. DHW can also be Switch ON/OFF
by Master controller.
Valid signal is depending on setting [Trigger type] of DHW Boost referring to 10.3.6.
● Set [Trigger type] as [Closed]
ON
DHW boost
signal
open
close
controller
OFF
ON
DHW
OFF
● Set [Trigger type] as [Open]
ON
DHW boost
signal
open
close
controller
OFF
ON
DHW
OFF
