286
Control function
(5) Demand ON/OFF1 and Demand ON/OFF2
Switch ON/OFF and Thermo ON/OFF of Corresponding room is controlled by an input of an external contact signal.
Corresponding room thermostat can also be Switch ON/OFF by Rooms function on Master controller.
(6) Swimming pool Demand ON/OFF
Switch ON/OFF and Demand ON/OFF of SWP is controlled by an input of an external contact signal.
SWP can also be Switch ON/OFF by Master controller.
Demand
ON/OFF1
Demand
ON/OFF2
signal
open
close
controller
OFF
ON
Thermo ON
Corresponding Room
Thermo OFF
RUN
Corresponding Room
STOP
Swimming
Pool Demand
ON/OFF
signal
open
close
controller
OFF
ON
Demand ON
Swimming Pool
Demand OFF
RUN
Swimming Pool
STOP
