General information
1.1.2 Line-Up of Hi-Therma Integra
It consists of one outdoor unit and one indoor unit. The outdoor unit extracts the heat present in the air, increases its
refrigerant temperature and transmits it to the water circuit using the plate heat exchanger of the indoor unit, where the heat
is taken to radiators (fan-coils), underoor heating components or both (two circuit temperature area). In terms of outdoor
unit, the Hi-Therma Integra series adopt the same outdoor unit as that of the Hi-Therma Split. As for the Hi-Therma Integra
indoor unit, water module and DHW are integrated as a whole, making it more convenient to provide customers with domestic
hot water. It is also more convenient to place Integra indoors to be more consistent with the furniture and appliances styles.
Integra takes up a smaller area, which is easier for installation and maintenance.
Outdoor Unit
Capacity
HP 2 2.5 3
kW 4.4 6.0 8.0
Model AHW-044HCDS1 AHW-060HCDS1 AHW-080HCDS1
Indoor Unit
Capacity
HP 2 2.5 3
kW 4.4 6.0 8.0
Model AHS-044HCDSAA-23 AHS-060HCDSAA-23 AHS-080HCDSAA-23
1.1.3 Line-Up of Hi-Therma Monobloc
Hi-Therma Monobloc is a monobloc air to water heat pump system composed by only a special outdoor unit, which carries
out the function of an air-to-water heat pump. This results in an excellent solution when installation space available is limited.
Hi-Therma Monobloc is designed to be installed outdoors, in any kind of dwelling (house, apartment, villa…), whether in
a new construction or in an existing building. Installation work is greatly simplied thanks to the lack of refrigerant piping
connections.
Capacity
HP 2 3
kW 4.4 8.0
Model AHZ-044HCDS1 AHZ-080HCDS1
Model: AHW-044/060/080HCDS1
Model: AHS-044/060/080HCDSAA-23
