General data
2.5.3 Hi-Therma Monobloc
Outdoor part
MODEL 044(2.0HP)/080(3.0HP)
For compressor
Pressure switches Automatic reset, non-adjustable
High
Cut-out
MPa
4.4±0.15
Cut-in 3.40±0.2
Low
Cut-out
MPa
0.05±0.03
Cut-in 0.15±0.03
Fuse capacity on PCB6 (F201) 220-240V ~ 50Hz A 30
CCP timer - Non adjustable
Setting time min 3
For condenser fan motor Internal Thermostat - Automatic Reset, Non-Adjustable
Indoor part
MODEL 044(2.0HP)/080(3.0HP)
For Auxiliary electric heaters
Automatic Reset Thermostat °C --
Temperature fuse °C --
Fuse capacity 220-240V ~ 50Hz A 20
For water circulation
Low water pressure protection Condition 1 Pw<0.3Bar for 180 seconds
High water pressure protection Condition 2 Pw>4.0Bar for 180 seconds
Minimum water ow rate m
3
/h 0.5(044)/0.6(080)
Water pump control - Water Pump status by feedback control
For the control circuit Fuse capacity 220-240V ~ 50Hz A 10 (Inside PCB1,EFR1)
For DHW Electric Heater Fuse capacity 220-240V ~ 50Hz A 20
