Installation
Auxiliary sensor - Setting before shipment
Mark Description Default settings Available auxiliary sensor codes
A1 Auxsensor 1 a - 01 (Tow3) a - 00 ~ 13
A2 Auxsensor 2 a - 03 (Tsolar) a - 00 ~ 13
A3 Auxsensor 3 a - 02 (Tswp) a - 00 ~ 13
A4 Auxsensor 4 a - 05 (Tow2) a - 00 ~ 13
A5 Auxsensor 5 a - 00 (No Function) a - 00 ~ 13
A6 Auxsensor 6 a - 07 (Room_amb1) a - 00 ~ 13
A7 Auxsensor 7 a - 08 (Room_amb2) a - 00 ~ 13
Auxiliary sensor codes - All Auxiliary sensor codes descriptions:
Auxiliary
sensor codes
Mark Description
a - 00 No Function -
a - 01 Tow3
This sensor is used in case to combine Unit with hydraulic separator to detect Hot
water temperature detection of hydraulic separator .
a - 02 Tswp
In case of combining Unit with swimming pool, this sensor is used to detect swimming
pool water temperature.
a - 03 Tsolar
In case of combining Unit with solar panels, this sensor is used to Detect Hot water
temperature of solar panels .
a - 04 Ta_ao
Optional Second Outdoor Ambient Temperature sensor accessory can be connected
to the Auxiliary sensor in case that the heat pump is located in a non-suitable position
for this measurement.
a - 05 Tow2
“Tow2” to detect outlet water temperature of Water Cycle 2.
a - 06 duty
Used to detect duty signal when duty signal control is Enabled, the duty signal type
can be 0-10V, 0-5V or 10-20mA.
a - 07 Room_amb1
Rooms function on master controller is selected as room thermostat, and in this
a - 08 Room_amb2
a - 09 Room_amb3
a - 10 Room_amb4
a - 11 Room_amb5
a - 12 Room_amb6
a - 13 Room_amb7
