Hi-Therma Integra system - Indoor unit (AHS-044/060/080HCDSAA-23)
At the connection of water pipe nut and valve body, a rubber gasket needs to be installed to prevent water leakage.
When removing the valve body, be careful not to damage the gasket. If damaged, it needs to be replaced with a new one;
Proceed in a reverse way to reassemble, and check whether there is water leakage after reassembly.
The cord clamp used to bundle the valve body needs to be cut during the disassembly process. When reassembling in a reverse way
than disassembling, it is no longer necessary to bundle the cord clamp.
