442
Hi-Therma Monobloc System (AHZ-044/080HCDS1)
2. Pull the Rear cover backwards and remove it
2. Pull the Valve cover upwards and remove it.
Rear cover
2.4.1.6
Removing the Valve Cover
Remove the service cover, as explained in “2.3.1.2 Removing the Service cover”
Remove the rear cover, as explained in “2.3.1.5 Removing the Rear cover”
Then,
1.
Valve cover
Valve cover
