2 Equipment Description
2.27 EUCN Cable System
160 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Initial Switch set up using “Express Setup”
System LED
LED Color
Description
Blinking green
The switch power-on self-test (POST) is running.
Solid green
POST has completed.
Red
The switch has failed POST.
Setup LED
LED Color
Description
Blinking green
The switch is not configured.
Solid green
Start a browser session on the PC.
Port LED
LED Color
Description
Blinking green
The switch Express Setup button is pressed.
A Category 5 Ethernet cable connects the blinking
switch port to the Ethernet port on a PC.
Pwr A LED
LED Color
Description
Solid green
The switch is properly powered up.
Dark (Off)
The switch is not powered up.
Verifying Port Connectivity
After the switch port is connected to another device.
Port LED
LED Color
Description
Amber
The switch is establishing a link to the connected
device. This process takes about 30 seconds.
Solid green
The switch and target device have established a
link.
Dark (Off)
The target device might not be turned on or there
might be a cable problem.
Normal Operating Mode
The switch is completely configured and connectivity with the target device is already established.
LED Color
Description
Flashing green
Communication between the port and target
device is occurring.
Flashing green interspersed with flashing amber
OR solid amber
A problem exists with this port to target device
interface.Check the port configuration and cable
integrity. If OK and condition still persists, contact
