4 Fault Isolation
4.3 Fault Isolation Concepts
330 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Table 58 Communications and Control Processor Hard Failure Codes
Error
Code
CPU
Failure Mnemonic
Description
Corrective Action
(See Table 57)
080D
Comm
CRASH
Send of mailbox data to DBIRET
failed.
2, 1
080E
Comm
CRASH
Set of IMR free EF failed.
2 1
080F
Comm
CRASH
Wait for CCI receive EF failed.
2, 1
0810
Comm
CRASH
Reset of CCI receive EF failed.
2, 1
0811
Comm
CRASH
No IMR so cannot perform clean
swap.
2, 1
0812
Comm
CRASH
Reset of TMOT event flag failed.
2, 1
0813
to
08FF
Comm
CRASH
Reserved for future CCI Subsystem
crash codes.
1
0900
Comm
CRASH
Mail box send to DBIGET failed.
2, 1
0901
Comm
CRASH
Pause completion returned illegal
code.
2, 1
0902
Comm
CRASH
Reset of no resource EF failed.
2, 1
0903
Comm
CRASH
Wait for message if record EF failed
2, 1
0904
Comm
CRASH
Reset of DBl_ASSO_Rec EF failed.
2, 1
0905
Comm
CRASH
Wait for Asso record failed.
2, 1
0906
Comm
CRASH
Mail box receive of input data failed.
2, 1
0907
Comm
CRASH
Mail box send of response to user
failed.
2, 1
0908
Comrn
CRASH
Mailbox receive of data from servers
failed.
2, 1
0909
Comm
CRASH
Incorrect priority mailbox received.
2, 1
090A
Comm
CRASH
Illegal ASSOC record returned.
2, 1
090B
Comm
CRASH
Illegal MIR record returned.
2, 1
090C
to
09FF
Comm
CRASH
Reserved for future DBI Subsystem
crash codes.
1
0A00
Comm
CRASH
Redundancy task reset EF failure.
2, 1
0A01
Comm
CRASH
Redundancy task set timed EF failure.
2, 1
0A02
Comm
CRASH
Redundancy task change priority
failure.
2, 1
0A03
Comm
CRASH
I/O Link timeout.
2, 6, 7, 1
0A04
Comm
CRASH
I/O Link in primary failed.
2, 6, 7, 1
0A05
Comm
CRASH
Spare crash 1.
1
