Honeywell HPM User Manual

4 Fault Isolation
4.3 Fault Isolation Concepts
R688 HPM High-Performance Process Manager Service 331
December 2020 Honeywell
Table 58 Communications and Control Processor Hard Failure Codes
Error
Code
CPU
Failure Mnemonic
Description
Corrective Action
(See Table 57)
0A06
Comm
CRASH
Timeout Entering Ring.
2,15,1
0A07
Comm
CRASH
Set timeout EF failure.
2, 1
0A08
Comm
CRASH
Timeout failure.
2, 1
0A09
Comm
CRASH
Set timeout EF failure 2.
2, 1
0A0A
Comm
CRASH
Secondary is wrong Pl.
2, 1
0A0B
Comm
CRASH
Timeout failure 2.
2, 1
0A0C
Comm
CRASH
Terminate failed.
2, 1
0A0D
Comm
CRASH
Spare crash 4.
1
0A0E
Comm
CRASH
Illegal pause status.
2, 1
0A0F
Comm
CRASH
Could not read own Checkpoint.
2, 6, 1
0A10
Comm
CRASH
Could not gain I/O Link.
2, 6, 7, 1
0A11
Comm
CRASH
Control processor failure detected.
14
0A12
Comm
CRASH
Control card mismatch
1
0A13
Comm
CRASH
Secondary lost synch.
18, 3, 10, 6
0A14
Comm
CRASH
Secondary incompatible database
2, 1
0A15
Comm
CRASH
Set EF failure.
2, 1
0A16
Comm
CRASH
Wait EF failure.
2, 1
0A17
Comm
CRASH
Could not write own Checkpoint.
2, 6, 1
0A18
Comm
CRASH
Primary timesynch hardware failure
2, 6, 1
0A19
Comm
CRASH
Secondary timesynch hardware
failure.
2, 6, 1
0A1A
Comm
CRASH
Control watchdog timed out.
2, 6, 1
0A1B
Comm
CRASH
I/O Link watchdog timed out.
2, 6, 7, 1
0A1C
Comm
CRASH
Control processor in reset.
2, 6, 1
0A1D
Comm
CRASH
I/O Link processor in reset.
2, 6, 7, 1
0A1E
Comm
CRASH
Comm database checksum compare
failed
2
0A1F
Comm
CRASH
Reserved for future RDN Subsystem
crash codes.
1
0A20
Comm
CRASH
UCN in primary has failed.
3, 8, 6, 1
0A21
Comm
CRASH
Secondary alone on UCN.
3, 8, 6,1
0A22
Comm
CRASH
EHPM Firmware Image (also known
as the Application Image) has failed.
22
