Honeywell HPM User Manual

9 Spare Parts
9.2 Periodic Maintenance Parts
480 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Table 88 Non-Conformally Coated HPM ORU Parts List
Name
Description
Part Number
GI Module Connector
Comp-type terminal connector for GI Modules
51191738-100
Crimp-type terminal connector for GI Modules
51191737-100
14-20 AWG wire crimp pins for above connector
51191737-201
MISCELLANEOUS COMPONENTS
Card Case
Plastic case for IOP cards
51304072-100
Plastic case for HPMM cards
51304072-200
Card Label
Label for HPM UCN Interface module
51109470-100
Label for High-Performance Comm/Control card
51109604-100
Label for High-Performance I/O Link card
51109605-100
Label - Plain blue for IOP filler card
51109474-100
Label for Low Level Analog Input IOP
51109475-100
Label for High Level Analog Input IOP
51109476-100
Label for Analog Output IOP
51109477-100
Label for Digital Input IOP
51109478-100
Label for Digital Output IOP
51109479-100
Label for I/O Link Extender
51109480-100
Label for Low Level Multiplexer IOP
51109486-100
Label for Smart Transmitter Interface IOP
51109494-100
Label for Serial Device Interface IOP
51109568-100
Label for Serial Interface IOP
51109607-100
FTA Plug-in Terminal Block
8 Point terminal block
51190694-108
12 Point terminal block
51190694-112
8 Point terminal block, labeled 1-8, gold contacts, for
LLAI
51190787-408
8 Point terminal block, labeled 9-16, gold contacts, for
LLAI
51190787-508
11 Point terminal block, labeled 9-19, gold contacts, for
LLAI
51190787-411
Terminal Block Cover
Cover for terminals on 8-channel LLAI FTA
51201569-100
Cabinet Fan Assembly
Cabinet fan assembly, 115 Vac without alarm
51304074-100
Cabinet fan assembly, 230 Vac without alarm
51304074-200
Cabinet Fan
Fan, 115 Vac (replacement for 51304074-100)
68A8976P1
