Honeywell HPM User Manual

9 Spare Parts
9.2 Periodic Maintenance Parts
R688 HPM High-Performance Process Manager Service 481
December 2020 Honeywell
Table 88 Non-Conformally Coated HPM ORU Parts List
Name
Description
Part Number
Fan, 230 Vac (replacement for 51304074-200)
68A8976P2
Cabinet Fan Assembly
Cabinet fan assembly, 115 Vac with alarm
51303940-100
Cabinet fan assembly, 230 Vac with alarm
51303940-200
Cabinet Fan Assembly PWB
PWB, 115 Vac (replacement for 51303940-100)
51201475-100
PWB, 230 Vac (replacement for 51303940-200)
51201475-200
Left 7- Slot Card File (MU-HPFH01)
Left 7-Slot HPMM/IOPcard file assy (slots 1-7)
51404125-100
Left 7- Slot Card File (MU-HPFH03)
Left 7-Slot HPMM card file assy (slots 1-7)
51404191-125
Left 7- Slot Card File (MU-HPFI03)
Left 7-Slot IOP card file assy (slots 1-7)
51404191-225
Left 7- Slot Card File Backpanel
Left 7-Slot card file backpanel assy (slots 1-7)
51401626-100
Right 7- Slot Card File (MU-
HPFH11)
Right 7- Slot HPMM/IOP card file assy (9-15)
51404126-100
Right 7- Slot Card File (MU-
HPFH13)
Right 7- Slot HPMM card file assy (slots 9-15)
51404192-125
Right 7- Slot Card File (MU-HPFI13)
Right 7- Slot IOP card file assy (slots 9-15)
51404192-225
Right 7- Slot Card File Backpanel
Right 7- Slot card file backpanel assy (slots 9-15)
51401629-100
15-Slot Card File (MU-HPFX02)
15-Slot HPMM/IOP card file assy (slots 1-15)
51404127-100
15-Slot Card File (MU-HPFX03)
15-Slot HPMM card file assy (slots 1-15)
51404193-125
15-Slot Card File (MU-HPFI23)
15-Slot IOP card file assy (slots 1-15)
51404193-225
15-Slot Card File Backpanel
15-Slot card file backpanel assy (slots 1-15)
51401632-100
IOP Only Card File (MU-IOFX02)
15 IOP Only card file assembly
51401546-100
IOP Only Card File Backpanel
15 IOP Only card file backpanel assembly
51402599-100
IOP Only Card File (MU-IOFX03)
15 IOP Only card file assembly
51404210-125
IOP Only Card File Backpanel
15 IOP Only card file backpanel assembly
51402599-125
Filler Plate
Filler plate between 7-Slot card files
51304720-100
Opto-Isolator
Solid-state opto-isolator for card files
51190516-202
Fuse Holder/Puller
Fuse holder/puller (15 IOP card file)
51190586-100
Fuse Holder/Puller
Fuse holder/puller (HPMM card files)
51309123-100
Jumper
Card file UCN node/I/O Link address plug jumper
51190624-900
