9. Problem Solving
Error
Code
Message Possible Cause Remedial Action
70 Cannot clear Inhibit because
the channel has been inhibited
automatically
A mV input channel has
not yet been calibrated
or channel configuration
was interrupted, or the
inhibit delay time is
active, or the sensor/
transmitter is signalling
inhibit
1. For a mV channel, calibrate the channel (see
Commissioning, Calibrating a mV input channel).
2. If this is not the cause, go to System
Conguration, then System Setup.
3. Select the module with the inhibited channel, and
select Normal State.
4. If this is not successful, go to Extras then Event
History to check if an Inhibit Delay Time is active. The
inhibit condition will clear after the Delay Time has
expired.
5. If there is no Delay Time active, then investigate
the conditions at the sensor/transmitter.
71 Cannot reset because the {0} is still
active (where {0} is alarm, fault or
warning)
The field device is still
signalling an active
alarm, fault or warning
Investigate the conditions at the field device.
72 Cannot reset all events for this
channel because one or more events
are still active
Some alarms, faults or
warnings on the channel
have been reset, but
others are still active
Investigate the conditions at the field device.
73 Replace operation cannot be
performed; module type of new
module is not compatible.
Replacement module
is incorrect type or not
recognised by the CCB
1. Check and confirm that the replacement module is
of the correct type.
2. Re-initialise the ring network and try again.
3. If the error persists, update the CCB firmware.
4. If the problem persists, please contact your local
service representative.
74 Not used
75 Not used
76 Not used
77 Not used
78 Not used
79 The Input Module cannot be
commissioned: The maximum
number of 16 Input Modules has
already been commissioned on the
system.
Touchpoint Pro has a
maximum capacity of
16 Input and 32 Output
Modules
If more channels than 64 inputs and 128 outputs
are required an additional Touchpoint Pro system is
needed. Contact your local representative to discuss
your requirements
80 The Output Module cannot be
commissioned: The maximum
number of 32 Output Modules has
already been commissioned on the
system.
Please refer to error 79 Please refer to error 79
81 Invalid test sequence CCB receives wrong Test
sequence for Relay tests
Please refer to error 2
82 The user could not be added;
invalid user name. Please choose a
different user name and try again.
The user name must be
4 to 20 characters long
Please choose a user name that meets the
requirements and try again
