Honeywell touchpoint Pro - Page 233

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
233
20. Appendix 7 - Logged events and
where they are displayed
Event Comment
Displayed
Specic
Channel Type
(if applicable)
Input
Details
screen
Output
Details
screen
Active
Events
screen
Inputs /
Outputs
screen
Fault Acknowledged All
Fault Cleared
Field Device Detached
Field Device detected mA, mV
Field Input Test Mode
Acknowledged
Field Inputs Test ended
Field Inputs Test started
✔
First Span Calibration Logs the first span calibration for a
channel
mV
Gas Over Range Calculated gas concentration is
greater than the configured ‘Gas
Over Range Limit’
✔
mA, mV
Gas Over Range Cleared mA, mV
Gas Under Range Calculated gas concentration is
less than the configured ‘Gas Under
Range Limit’
✔
mA, mV
Gas Under Range Cleared mA, mV
Hardware Fault Hardware fault has occurred within
the Control Module
Hardware Fault acknowledged
Hardware Fault cleared
Hold Time Active Configured delay for ROM channel
de-activation.
ROM
I/O Module Removed All
Inhibit
✔ ✔ ✔
All
Inhibit by CCB Channel has been inhibited by the
CCB because it is being configured,
or one of the channels on the same
module is being configured
Inhibit Cleared All
Inhibit Cleared by CCB
Input Activation Acknowledged Logged when DIM input active is
acknowledged
DIM
Input Active DIM channel active
✔ ✔ ✔
DIM
Input Cleared Logged when DIM input active is
cleared
DIM
Input Force Cleared
