Honeywell UDC2800 User Manual

94
Algorithm Set Up Group
Introduction
This data deals with various algorithms in the controller and Timer
functions.
The Timer section allows you to configure a time-out period and to
select the timer start by either the keyboard ( RUN/HOLD key) or
Alarm 2. An optional digital input can also be configured to the start
the timer. The timer display is selectable as either “Time Remaining”
or “Elapsed Time”.
Alarm 1 is activated at the end of the time-out period. When the timer
is enabled, it has exclusive control of the alarm 1 relay—any previous
alarm 1 configuration is ignored. At time-out, the timer is ready to be
activated again by whatever action has been configured.
Function Prompts
Table 4-8: Algorithm Group Function Prompts
Function Prompt
Selections or Range of
Setting
Parameter Definition
Control Algorithm The Control Algorithm lets you
select the type of control that is best
for your process.
Disable
Disable- Disables Algorithm
ATTENTION: Tuning, SP
program, and Accutune
groups depend on the control
algorithm. If the control
algorithm is disabled, all
three groups can not display
on the main menu.
On-Off ON/OFF is the simplest control type.
The output can be either ON (100
%) or OFF (0 %). The Process
Variable (PV) is compared with the
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
