Honeywell UDC2800 User Manual

166
Current Calib Set Up Group
Introduction
This group appears when Output Algorithms of Output set up group is
configured as Current Simplex, Current Duplex, Current Time, or Time
Current. See Output Set Up Group for more information.
Function Prompts
Table 4-20: Current Calib Group Function Prompts
Function
Prompt
Selections or Range of
Setting
Parameter Definition
Zero Value It ranges from 0 to
65535.
The desired 0 % output is read on the
milliammeter, use the values shown below
depending on the action of your controller.
Normally, this will be the setting that produces
4 mA.
Span Value It ranges from 0 to
65535.
The desired 100 % output is read on the
milliammeter, use the values shown below
depending on the action of your controller.
Normally, this will be the setting that produces
20 mA.
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
