148
Communications Group
Introduction
The Communications group lets you configure the controller with
Easyset, a mobile app that communicates through Bluetooth, and
lets a Modbus® client/master host communicate with the controller
via Ethernet TCP/IP protocol.
A controller with the Ethernet option looks for messages from the
host computer. If these messages are not received within the
configured shed time, the controller will SHED from the
communications link and return to stand-alone operation. You can
also set the SHED output mode and setpoint recall, and
communication units.
Up to 99 addresses can be configured over this link. The number of
units that can be configured depends on the link length, with 31
being the maximum for short link lengths and 15 drops being the
maximum at the maximum link length.
Function Prompts
Table 4-14: Communications Group Function Prompts
Function
Prompt
Selections or
Range of
Setting
Parameter Definition
Bluetooth
Function
Disable
Enable
Disables/enables the Bluetooth function.
Bluetooth ID UXXXXXXXX Read only. It is an ID that is assigned to a controller
that is to be used with the communications option.
Bluetooth
Mac Address
XX:XX:XX:XX:XX
:XX
Read only.
Communicati
on Type
Communication type selection - enables the RS485
or Ethernet communication port.
Disable Disable —Disables communications option.
Modbus Modbus —Enables RS485 Modbus RTU
communication port.
Chapter 4 - Configuration
