Honeywell UDC2800 User Manual

186
Setpoints
Introduction
You can configure the following setpoints for the UDC2800
controller.
n
A Single Local Setpoint
n
2 Local Setpoints
n
3 Local Setpoints
n
4 Local Setpoints
n
Up to 4 Local Setpoints and one Remote Setpoint
See Control Set Up Group for more information.
See "Control Set Up Group" in UDC2800 Product Manual.
Change the Setpoint value
Table 5-5: Procedure for Changing the Local Setpoints
Step Operation Press Result
1 Select the
Setpoint
Lower
Display key
Until you see:
Lower Display = SP or 2SP or 3SP, or 4SP (Value)
2 Change the
Value
Increment
key or
Decrement
key
To change the Local Setpoint to the value at which
you want the process maintained. The display
“blinks” if you attempt to enter setpoint values
beyond the high and low limits.
The configured setpoint will be stored immediately.
Chapter 5 - Monitoring and Operating the Controller

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
