Honeywell UDC2800 - Configuration Procedure

Setup Group Function Prompts
Auxiliary Calib
(Calibration)
Status
Configuration Procedure
Introduction
Each of the Set Up groups and their functions are pre-configured at
the factory.
The factory settings are shown in Table Security Group Function
Prompts through Table Display Group Function Prompts.
If you want to change any of these selections or values, follow the
procedure in Table Configuration Procedure. This procedure tells you
the keys to press to get to any Set Up group and any associated
Function parameter prompt.
Procedure
See Operator Interface for more information of keys.
Table 4-2: Configuration Procedure
Step Operation Press Result
1 Enter Set Up Mode Setup key Enter in the first set up group,
Security.
2 Select any Set Up
Group
Setup key or
Increment key or
Decrement key
Sequentially displays the other set
up groups shown in the prompt
hierarchy. See Configuration Prompt
Hierarchy for more information.
You can also use the Increment key
or Decrement keys to scan the set
up groups in both directions. Stop
at the set up group title that
describes the group of parameters
you want to configure. Then proceed
to the next step.
71
Chapter 4 - Configuration
