Honeywell UDC2800 User Manual

Slidewire Calib Set Up Group
Introduction
This group appears when Input 2 Type of the Input 2 set up group is
configured as Slidewire, and Output Algorithm of the Output set up
group is Position Proportion. You can calibrate the controller output
manually or let the controller calibrate the output automatically.
Function Prompts
Table 4-19: Slidewire Group Function Prompts
Function
Prompt
Selections
or Range
Parameter Definition
Position
Proportion
Disable Disable the calibration.
Do Auto If the slidewire has never been calibrated, you must use Do
Auto first, and the controller relays automatically move the
motor in the proper direction.
Do Manual The motor does not move, you can change the value with
the Increment key and Decrement key.
Zero Value 1~1023 Set 0% value
Span Value 1~1023 Set 100% value
NOTE: When the slide wire is in failsafe mode and a power cycle is closed, select
the auto/manual or increment/decrement key to change to normal mode.
165
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
