Honeywell UDC2800 - Set Point Program Segment Map

422
Parameter Description
Register Address
Access Description
Hex Decimal
Hold
1-15: Unused
Engineering Units for Ramp
Segments
2100
48449 R/W Bit Packed
Bit 0: 0: Hrs:Mins
0: 1: Degrees/Min
1: 1: Degrees/Hour
2-15: Unused
Program Start Segment 1 ~ 8 2101
48450 R/W Bit Packed
Bit 0: 1= Start
Segment 1
1: 1= Start Segment
2
⁞
7: 1= Start Segment
8
Program Recycles 2102
48451 R/W Unsigned 16 bit
integer
0 ~ 99
Set Point Program Segment Map
A profile can contain up to 64 segments depending on the
instrument. Each segment is made up of 8 registers. The segment
mapping for setpoint programmer #1~8 is shown below.
Table 12-29: Set Point Program Segment Map
Start Address End Address Description
2800 2807 Set Point Programmer #1 Segment 1
2808 280F Set Point Programmer #1 Segment 2
