Honeywell UDC2800 User Manual

138
Options Set Up Group
Introduction
The Options group lets you configure the remote mode switch
(Digital Inputs) to a specific contact closure response, or configure
the Auxiliary Output to be a specific selection with desired scaling.
Function Prompts
Table 4-13: Options Group Function Prompts
Function Prompt
Selections or Range
of Setting
Parameter Definition
Auxiliary Output
ATTENTION: Prompts for the
Auxiliary Output selection
appear only if one of the
Auxiliary Output boards is
installed.
This selection provides an mA output
representing one of several control
parameters. The display for auxiliary
output viewing will be in engineering
units for all but output. Output will
be displayed in percent.
ATTENTION: Other prompts
affected by these selections:
4mA VAL and 20mA VAL.
ATTENTION: Output cannot be
configured when Three
Position Step Control is used.
Disable No Auxiliary Output
Input 2 Input 2 represents the value of the
configured range of input 2.
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
