48
Mounting Procedure
Table 3-4: Mounting Procedure
Step Action
1 Mark and cut out the controller hole in the panel according to the dimension
information. See Overall Dimensions for more information.
2 Orient the case properly and slide it through the panel hole from the front.
3 Remove the mounting kit from the shipping container and install the kit as
follows:
l
For normal (NEMA3/IP55) installation two mounting clips are required.
Insert the prongs of the clips into the two holes in the top and bottom
center of the case
l
For water-protected (NEMA4X/IP66) installation four mounting clips
are required. There are two options of where to install the mounting
clips: 1) Insert the prongs of the clips into the two holes on the left and
right side of the top and bottom of the case or 2) on the center on each
of the four sides.
l
Tighten screws to 2 lb-inch (22 N•cm) to secure the case against the
panel. CAUTION:
CAUTION: Over tightening will cause distortion and the unit may not
seal properly.
4 For water-protected installation, install four screws with washers into the four
recessed areas in the corners of the front bezel.Push the point of the screw
through the center piercing the elastomeric material and then tighten screws
to 5 lb-in (56 N•cm).
Chapter 3 - Installation
