152
Function
Prompt
Selections or
Range of
Setting
Parameter Definition
power is turned off and on.
ATTENTION: The instrument does not have to
be connected to the external communications
link in order to perform this test. If it is
connected, only one instrument should run the
loopback test at a time. The host computer
should not be transmitting on the link while the
loopback test is active.
Alarms Set Up Group
Introduction
An alarm is an indication that an event that you have configured (for
example—Process Variable) has exceeded one or more alarm limits.
There are two alarms available. Each alarm has two setpoints. You
can configure each of these two setpoints to alarm on various
controller parameters.
There are two alarm output selections, High and Low. You can
configure each setpoint to alarm either High or Low. These are called
single alarms.
You can also configure the two setpoints to alarm on the same event
and to alarm both high and low. A single adjustable Hysteresis of 0
% to 100 % is configurable for the alarm setpoint.
See the table Alarm Relay Contact Information for Alarm relay
contact information.
The prompts for the Alarm Outputs appear whether or not the alarm
relays are physically present. This allows the Alarm status to be
shown on the display and/or sent via communications to a host
computer.
Chapter 4 - Configuration
