Function Prompts
Table 4-15: ALARMS Group Function Prompts
Function
Prompt
Selections or Range
of Setting
Parameter Definition
A1S1 Type Alarm 1 Setpoint 1 Type —Select what you
want Setpoint 1 of Alarm 1 to represent. It
can represent the Process Variable,
Deviation, Input 1, Input 2, Output, and if you
have a model with communications, you can
configure the controller to alarm on SHED. If
you have setpoint programming, you can
alarm when a segment goes ON or OFF.
l
None
l
Input 1
l
Input 2
l
PV
l
Deviation
l
Output
l
SHED
l
Event On
l
Event Off
l
Manual
l
Remote SP
l
Failsafe
l
PV Rate of Change
l
DI 1 Actuated
l
DI 2 Actuated
l
Loop Break
l
TC Warning
l
TC Failed
l
PV Hold
l
No Alarm
l
Input 1
l
Input 2
l
Process Variable
l
Deviation (NOTE 1)
l
Output (NOTE 8)
l
Shed from Communications
l
Event On (SP Programming) (NOTE 7)
l
Event Off (SP Programming) (NOTE 7)
l
Alarm On Manual Mode (NOTE 2)
l
Remote Setpoint (NOTE 6)
l
Failsafe
l
PV Rate of Change
l
Digital Input 1 Actuated
l
Digital Input 2 Actuated
l
Loop Break (NOTE 3)
l
Thermocouple Warning (NOTE 4)
l
Thermocouple Fail (NOTE 5)
l
PV Hold
153
Chapter 4 - Configuration
