Honeywell UDC2800 User Manual

404
Parameter Description
Register Address
Access Description
Hex Decimal
integer
Write to
location Holds
Profile;
Data ignored
SP Program 7
Table 12-19: Setpoint Program 7
Parameter Description
Register Address
Access Description
Hex Decimal
SP Program Output 1E60 47777 R Setpoint
Program output
value
(engineering
unit)
Current Segment Number
1E62 47779 R Floating Point;
1...Max
Segment #
A write changes
the segment
number
Segment Time Remaining 1E68 47785
R Floating Point
in Seconds or
Time Units
Status 1E6B 47788
R Bit 0: 1=Ready
1: 1=Run
2: 1=Hold
3: 1=End
4: 1=Time Units
in Seconds
Chapter 12 - Standard Modbus Read, Write and Override Parameters

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
