Honeywell UDC2800 User Manual

88
Function Prompt
Selections or
Range of
Setting
Parameter Definition
(0-99 hours:0-
59 minutes
Segment 3 Ramp
Segment 4 SP &
Segment 4 Time
Segment 5 Ramp
Segment 6 SP &
Segment 6 Time
Segment 7 Ramp
Segment 8 SP &
Segment 8 Tim
Selections are
same as above.
Same as above
NOTE: The SPP program initiates in the incremental order from 1 to 8. For
example SP program 1, SP program 2 and so on.
SP PROG2 ~ PROG 8 Set Up Group
Introduction
Setpoint Program 2 ~8 have same parameters, and they can be
configured in the corresponding groups.
SP Program 2~8 only appear when SP Program is enabled in the SP
Ramp set up group.
Function Prompts
Table 4-6: SP Program 2~8 Group Function Prompts
Function Prompt
Selections or Range of
Setting
Parameter Definition
Start Segment 1 to 8 Start Segment Number
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
