Function Prompt
Selections or
Range of
Setting
Parameter Definition
Ramp Unit Engineering Units for Ramp Segments
Time Hrs:Mins Time in hours: minutes
Rate EU/Min Rate in Engineering units per minute
0~999 EU/Min
Rate EU/Hr Rate in Engineering units per hour
0~999 EU/Hr
Recycles 0 to 99 recycles Number of Program Recycles
NOTE: In recycles program, if user select
To Begin; The recycles also begin from first
segment and first program. It also reset
recycles to all programs
NOTE: In recycles program, if user select
Rerun; the setpoint program to rerun from
the first segment in the current program
and it is do not effects recycle program.
Segment 1 Ramp 00:00 ~ 99:59
(0-99 hours:0-
59 minutes)
or
0 ~ 999 EU/Min
or
0 ~ 999 EU/Hr
Segment #1 Ramp Time/Rate
NOTE: This parameter is affected by the
Ramp Unit configuration. Select Time
Hrs:Mins , Rate EU/Mins, or Rate EU/Hrs at
prompt Ramp Unit. All ramps in this SP
Program will use the same selection.
NOTE: Press Increment Key and
Decrement Key at the same time to move
the current editable digit one step left if
required.
Segment 2 SP Within the
Setpoint limits
Segment #2 Soak Setpoint Value
Segment 2 Time 00:00 ~ 99:59 Segment #2 Soak Duration
87
Chapter 4 - Configuration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
