HP 8753E Service Manual

11. System Trace Noise (Only for Analyzers with
Option 006)
Specifications
Frequency Range Ratio System Trace Noise System Trace Noise
(Bfagnitudel)
OPh-3
30 kHz to 3 GHz
A/R
<O.O06dBrms
<O.O38O rms
30 kHz to 3 GHz B/R <0.006 dB m-s
<0.038" rms
3GHzto6GHz A/R <O.OlO dB rms <0.0700 rms
3GHzto6GHz B/R
<O.OlO dB nns
<o.070° rnls
1 At + 5 dBm into test port, 3 lcHz IF bandwidth, and CW sweep.
Required Equipment
Cable, APC-7, 24-inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP P/N 8120-4779
Analyzerwarmuptime: lhour
Perform this test to measure the system trace noise at designated CW
frequencies in both the A/R and B/R
ratioed measurements.
1. Connect the equipment as shown in Figure 2-32.
HP 8753E
NETWORK ANALYZER
Figure Z-32. System Trace Noise ‘Ikst Setup
2-66 System Verification and
Performance Tests
