8. If you have difficulty with the printer:
n If the interface on your printer is HP-IB, verify that the printer address is
set to 1 (or change the setting in the analyzer to match the printer).
n If the interface on your printer is serial or parallel, be sure that you
selected the printer port and the printer type correctly (refer to the
HP
8753ENetuwrk
Anulgzer User’s
Guide
for more information on how to
perform these tasks).
10. The analyzer displays Sys Ver
Init
DONE; the initialization procedure is
complete.
Caution
Do
NOT
press (Preset or recall another instrument state. You
must use the instrument state that you loaded during the
initialization procedure.
Measurement Calibration
14. Connect the “open” end of the open/short combination (supplied in the
calibration kit) to reference test port 1, as shown in Figure 2-2.
System Verifcationand 2-11
PerformanceTests
