Analyzer Options Available
Option
lD5,
High Stability Frequency Reference
This option offers
f0.05
ppm temperature stability from 0 to
60°
C
(referenced to
25O
C).
Option 002, Harmonic Mode
This option provides measurement of second or third harmonics of the test
device’s fundamental output signal. Frequency and power sweep are supported
in this mode. Harmonic frequencies can be measured up to the
maxinuun
frequency of the receiver. However, the fundamental frequency may not be
lower than 16 MHz.
Option 006, 6
GHz
Operation
This option extends the
maximurn
source and receiver frequency of the analyzer
to 6
GHz.
Option 010, Time Domain
This option displays the time domain response of a network by computing
the inverse Fourier transform of the frequency domain response. It shows
the response of a test device as a function of time or distance. Displaying the
reflection coefficient of a network versus time determines the magnitude and
location of each discontinuity. Displaying the transmission coefficient of a
network versus time determines the characteristics of individual transmission
paths Time domain operation retains all accuracy inherent with the correction
that is active in of such devices as SAW
filters,
SAW delay lines, RF cables, and
RF antennas.
Option 011, Receiver Configuration
This option
allows
front panel access to the R, A, and B samplers and receivers.
The transfer switch, couplers, and bias tees have been removed. Therefore,
external accessories are required to make most measurements
Service Equipment and Analyzer Options
l-7
