HP 8753E - Fractional-N Spur Avoidance and FM Sideband Adjustment

Fractional-N Spur Avoidance and
FM Sideband Adjustment
Required Equipment and ‘lbols
Spectrum Analyzer
....................................................
HP 8563E
HP-IB Cable
...................................................
HP
10833A/B/G/B
RF Cable 50 ohm, Type-N, 24-inch
...............................
HP P/N 81204781
Cable,
509 Coax, BNC (m) to BNC (m)
..............................
.HP 10503A
Non-metallic Adjustment lb01
................................
HP P/N 8830-0024
Antistatic Wrist Strap
........................................
HP P/N 9300-1367
Antistatic Wrist Strap Cord
..................................
HP P/N 9300-0980
Static-control Able Mat and Earth Ground Wire
............
HP P/N 9300-0797
Additional Required Equipment for 5013 Analyzers
Adapter APC-7 to Type-N (f)
. . . . .., . . . . . . . . . . . . . . . .., . . . . . . . . . . . . . . . HP 11525A
Additional Required Equipment for 75 ohm Analyzers
Minimum Loss Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP 11852B
Anulgm warmup time: 30 minutes.
This adjustment
minimizes the spurs caused by the API (analog phase
interpolator, on the fractional-N assembly) circuits. It
also improves the
sideband characteristics.
1. Connect the equipment as shown in Figure 3-22.
2. Make sure the instruments are set to their default HP-IB addresses:
HP 8753E = 16, Spectrum Analyzer = 18.
344 Adjustments and Correction Constants
