ADC Offset Correction Constants
(‘I&t
52)
Analyzer warmup
tim.e:
30 minutes.
These correction constants improve the dynamic accuracy by shifting small
signals to the most linear part of the ADC quantizing curve.
Note
This routine takes about three minutes.
2. Observe the analyzer for the results of the adjustment routine:
w
If the analyzer displays ADC Of
8
Cor DONE, you have completed this
procedure.
w
If the analyzer displays ADC Of
8
Cor FAIL, refer to the “Digital Control
Troubleshooting” chapter.
Adjustments and Correction Constants
3-17
