Service Key Menus
-
Service Features
The service feature menus are shown in
F’igure
10-3
and described in the
following paragraphs. The following keys access the service feature menus:
sg6103e
Figure 10-3. Service Feature Menus
Service Modes Menu
allows you to control and monitor various circuits
for troubleshooting.
tests the
Al3
and
Al4
fractional-N circuits. It
dOWS
YOU
to directly control and
monitor the output
frequency of the fractional-N
synthesizer (10 MHz to
60
MHZ).
Set the instrument to CW
sweep mode
ami
then set F’RACN
TUNE ON.
lo-18
Service Key Menus and Error Messages
