HP 8753E Service Manual

Correction Constants Retrieval Procedure
Required Equipment and Tools
EEPROM Backup Disk
Antistatic Wrist Strap . . . . . , . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HP P/N 9300-1367
Antistatic Wrist Strap Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP P/N 9300-0980
Static-control ‘Ihble Mat and Earth Ground Wire . . . . . . . . . . . . HP P/N 9300-0797
By using the current EEPROM backup disk, you can download the correction
constants data into the instrument
EEPROMs.
1.
2.
3.
4.
5.
6.
7.
Insert the “EEPROM Backup Disk” into the HP 8753E disk drive.
Make sure the A9 switch is in the Alter position.
* p f!g;-~ :>+?$?q&:. pL+y .::: .:: ) :.:::y ,,,,,,
Press t-1 ‘~~~~~~ ~~~~~~~~~~. Use the front panel knob
to highhght the IiIe “N12345” where N12345 represents the file name of the
EEPROM data for the analyzer. On the factory shipped EEPROM backup
disk, the filename is
PILEl.
i........... :..:..v..... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i. .,.. .““’ .:.:: :... :;:::;:j :.~,,.,,,,,~~~~~.~: :.::::::.:::.:::.:....:::::::::::::~.::::::::::
press Tm ~~~~~~~~~~ to download the come&ion constants data into
the instrument EEPROMs.
Perform “Option Numbers Correction Constant (Test 56). n
Press preset] and verify that good data was transferred to EEPROM by
performing a simple measurement.
Move the
A9 switch back to its Normal position when you are done working
with the instrument.
340 Adjustments and Correction Constants
