verifies the analyzer system operation by examining
the contents of the measurement calibration arrays.
The procedure is in the “System Verification and
Performance Tests” chapter. Information about the
calibration arrays is provided in the “Error Terms”
chapter.
generates and stores the correction constants.
For more information, refer to the “Adjustments”
chapter.
checks for correct operation of the display and GSP
board.
Test
Options Menu
accesses softkeys that affect the way tests (routines)
run, or supply necessary additional data.
resumes the test from where it was stopped.
toggles the repeat function on and off. When the
function is ON, the selected test will
rtm
10,000
times unless you press any key to stop it. The
analyzer shows the current number of passes and
fails.
toggles the record function on and off. When the
function is ON, certain test results are sent to
a printer via HP-IB. This is especially useful for
correction constants. The
indent
must be in
system controller mode or pass control mode to
print (refer to the “Printing, Plotting, and Saving
Measurement Results” chapter in the HP 87533
User’s
Guidt?.
selects either
NORMal
or
SPeCiaL
(tighter) limits for
the Operator’s Check. The SPCL limits are useful for
a guard band.
accesses the following Edit List menu to allow
modihcation
of the external power loss data table.
Service Key Menus and Error Messages
1
O-5
