Power Supply Theory
The power supply functional group consists of the
Al5
preregulator and the
A8 post regulator. These two assemblies comprise a switching power supply
that provides regulated DC voltages to power all assemblies in the analyzer. The
Al5
preregulator is enclosed in a casting at the rear of the instrument behind
the display. It is connected to the A8 post regulator by a wire bus A15Wl.
Figure
12-2 is a simplified block diagram of the power supply group.
2’
OFF DURING
L
ALL ON DURING
NORMAL OPERATION
NORMAL
OPERAlION
\
;ON
DURING
NORMAL OPERATION
sg6105e
Figure 12-2. Power Supply Functional Group, Simplified Block Diagram
Al5
Preregulator
The
Al5
preregulator steps down and
recti6es
the line voltage. It provides a
fully regulated
+5
V digital supply, and several preregulated voltages that go to
the A8 post regulator assembly for additional regulation.
The
Al5
preregulator assembly includes the line power module, a 60
kHz
switching preregulator, and overvoltage protection for the
+5
V digital supply.
It provides
LEDs,
visible from the rear of the instrument, to indicate either
normal or shutdown status.
Theory of Operation 12-5
