HP 8753E - Port 1 Noise Floor Level from 300 Khz to 3 Ghz (if BW = 10 Hz)

Port 1 Noise Floor Level from 300 kHz to 3 GHz
(IF BW = 10 Hz)
10. When the analyzer finishes the sweep, notice the mean value.
11. Convert the measured linear magnitude mean value to log magnitude, using
this equation.
Power (dBm) = 20 * [lOgIO(Zinear magnitude mean value)]
12. Write this calculated value on the “Performance Test Record.”
Port 2 Noise Floor Level from 300 kHz to 3 GHz
(IFBW = 1OHz)
15. When the analyzer finishes the sweep, notice the mean value.
16. Convert the measured linear magnitude mean value to log magnitude, using
this equation.
Power (dBm) = 20 * [log,,(Zinear magnitude mean value)]
17. Write this calculated value on the “Performance Test Record.”
System Verification and
2-39
Performance Tests
