HP 8753E Service Manual

18. ‘Ikst Port Output Harmonics
(Analyzers without Option 002)
Speciikations
1 For HP 87633 Option 075: + 8 dF%m source output;
limits valid for frequencies below 2 GHz
Equipment Required for 50 ohm Analyzers
Spectrum analyzer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP 85953
Cable, 509, type-N (m) to type-N (m), 24-inch . . . . . . . . . . . . . . . HP P/N 81204781
Adapter, APC-7 to type-N (f)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . HP 11524A
Adapter, type-N (m) to BNC (f) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .HP P/N 1250-1476
Cable, 503, BNC (m)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HP P/N 8120-1840
Additional Equipment Required for 75 ohm Analyzers
Minhmmvloss pad
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HP 11852B
z.$r warmup time: 30 minutes (network analyzer and spectrum
Perform this test to determine the spectral purity of the network analyzer
RF source. Use this procedure with HP 8753E network analyzers without
Option 002 (harmonic measurement capability).
System Verification and 2-l 07
Performance Tests

HP 8753E Specifications
