HP 8753E Performance ‘Ilest Record (8 of 13)
For 30 kHz-3 GEL Analyzers
Hewlett-Packard Company
Model HP 8766E
I&port Number
SerialNumber
Dllh?
bb 9. Calibration Coefficients (continued)
Test Description
Freqnency Bange SW.
Measured Value Measurement
(-1 WI
Uncertainty
WI
Reverse Direction
Trans. Tracking 300 kHz - 1.3 GHz f 1.5 f 0.006
Trans. Tracking 1.3GHz-3GHz f 1.5 f 0.009
Forward Direction
Load Match
3OOkHz-1.3GHz 1 18 f 0.1
Load Match 1.3GHz-3GHz 1 16 f 0.2
Reverse Direction
Directivity
300 kHz - 1.3 GHz > 35 f 0.9
Dire&vi@ 1.3GHz-3GHz 130 f 0.8
Reverse Direction
Source Match 300 kHz - 1.3 GHz 2 16 f 0.2
Source Match 1.3GHz-3GHz 1 16 f 0.2
Reverse Direction
Ben. Tracking 3OOkHz-1.3GHz f 1.5 f 0.001
Beil. Traclciug 1.3GHz-3GHz f 1.5 f 0.005
Performance Test Record 2a-9
