At the end of a successful loading, the

LEDs

for Channel 1 and

Testport

will remain on and the display

will

turn on indicating the version of

lirmware

that was loaded.

I.nCa13eofDifticulty

If the firmware did not load successfully, LED patterns on the front panel can

help you isolate the problem.

n If the following LED pattern is present, the firmware disk is not for use with

your instrument model. Check that the

firmware

disk used was for the

HP 8753E.

n If any of the following LED patterns are present,

defective.

LEDlhttern

CJIlCE2

B L T S

. .

. . .

. .

. . .

. .

the firmware disk may be

n If any other LED pattern is present, the CPU board is defective.

342

Adjustments and Correction Constants

HP 8753E Service Manual
