HP 8753E
NETWORK ANALYZER
Note
HP 8563A
PORTI
I
PORT2
I
50R MPE-N CABLE ASSEMBLY
HP 8753E
NETWORK ANALYZER
WITH OPTION
075
HP 8563A
SPECTRUM ANALYZER
PGRTl
I
PORT?:
I
sq641e
Figure 3-17. Frequency Accuracy Adjustment Setup
Make sure that the spectrum analyzer and network analyzer
references are not connected.
3.
4.
For Option lD5 Instruments Only: Remove the BNC-to-BNC jumper
that is connected between the “EXT REF” and the “10 MHz Precision
Reference,” as shown in Figure 3-19.
Set the spectrum analyzer measurement parameters as follows:
Adjustments and Correction Constants
