If the + 15 V and -12.6 V green
LEDs
light, troubleshoot for a short between
the motherboard connector pins
XA8P2
pins 6 and 36 (-12.6
V)
and the front
panel probe power connectors. Also check between motherboard connector pins
XA8P2
pins 4 and 34 (+ 15
V)
and the front panel probe power connectors.
Power Supply Troubleshooting
5-21
283
285
