Rear
Panel Interface Board Assembly
(A16)
Tools
Required
n
9/16
hex nut driver
n
3/16
hex nut driver
n
T-10
TORX screwdriver
n
T-15
TORX screwdriver
n
ESD (electrostatic discharge) grounding wrist strap
Removal
1. Disconnect the power cord and remove the top and bottom covers (refer to
“Covers” in this chapter).
2. If the
analyzer
has option
lD5,
remove the
high-stabiiity
frequency reference
jumper (item 1).
3. Remove the hardware that attaches the seven BNC connectors to the rear
panel (item 2).
4. Remove the hardware that attaches the interface connector to the rear panel
(item 3).
5. Remove the rear panel from the analyzer (refer to “Rear Panel Assembly” in
this chapter).
6. If the analyzer has option lD5, disconnect the cable (item 4) from the rear
panel interface board.
7. Disconnect the ribbon cable (item 5) from the rear panel interface board.
Replacement
1. Reverse the order of the removal procedure.
14-20
Assambly
Replacement and Post-Repair Procedures
