600

S:\HP892XX\USRGUIDE\manual\accessor.fb

Chapter 25, Modifications, Accessories, Manuals, Support

Accessories

Plug Type (Male)

Plug Descriptions

male/female

HP Part # (cable&

plug)

Cable Descriptions

90°/Straight 90°/

90°

8120-1351

8120-1703

90 inches, mint gray 90

inches, mint gray

Used in the following locations

Bahrain, British Indian Ocean Territories, Brunei

Canton, Cyprus

Enderbury Island, Equatorial Guinea

Falkland Islands, French Pacific Islands

Gambia, Ghana, Gibraltar, Guinea

Hong Kong

Ireland

Kenya, Kuwait

Macao, Malaysia, Mauritius

Nigeria

Qatar

Seychelles, Sierra Leone, Singapore, Southern Asia, Southern Pacific Islands, St. Helena, Sudan

Tanzania

Uganda, United Arab Emirates, United Kingdom

Yeman (Aden & Sana)
