Chapter 25, Modifications, Accessories, Manuals, Support

Accessories

Plug Type

Plug Descriptions

male/female

HP Part #

(cable &plug)

Cable Descriptions

Straight/Straight

Straight/90°

8120-1369

8120-0696

79 inches, gray

80 inches, gray

Used in the following locations

Argentina, Australia

China (People’s Republic)

New Zealand

Papua New Guinea

Uruguay

Western Samoa
